SR400EQM-SKG

SKG : Surreal Black Burst Gloss

COLOR VARIATION：

SPEC

SPECS
- neck type
- SR4 5pc Maple/Walnut neck
- top/back/body
- Quilted Maple top Nyatoh body
- fretboard
- Jatoba White dot inlay
- fret
- Medium frets
- bridge
- Accu-cast B300 bridge
- string space
- 19mm
- neck pickup
- PowerSpan Dual Coil neck pickup Passive
- bridge pickup
- PowerSpan Dual Coil bridge pickup Passive
- equaliser
- Ibanez Custom Electronics 3-band EQ w/3-way Power Tap switch
- factory tuning
- 1G,2D,3A,4E
- strings
- D'Addario® EXL165
- string gauge
- .045/.065/.085/.105
- hardware color
- Cosmo black
NECK DIMENSIONS
- - Scale :
  - 864mm /34"
  - a : Width
  - 38mm at NUT
  - b : Width
  - 62mm at 24F
  - c : Thickness
  - 19.5mm at 1F
  - d : Thickness
  - 21.5mm at 12F
  - Radius :
  - 305mmR
- DESCRIPTION

  Guitar Neck Diagram
  a: Width of the neck at the nut
  b: Width of the neck at the first fret
  c： Thickness of the neck at the first fret
  d: Thickness of the neck at the twelfth fret
  Radius: Radius of the fingerboard
CONTROLS

DESCRIPTION

With the bass held in the playing position, there are three small knobs closest to the lower edge of the body. Directionally, from the lower bout towards the neck knobs are treble boost/cut, mid boost/cut, and bass boost/cut. There are two larger knobs above these, closer to the bridge. The knob closest to the neck controls volume, and the knob next to it is the pickup balancer control. There is a 3-way power tap switch next to the balancer knob. When the switch is in neck position, the humbuckers are tapped. When the switch is in center position, the humbuckers are in series. when the switch is in bridge position, the humbuckers are in power tap mode, which is tapped with additional low end added.
FREQUENCY RESPONSE

DESCRIPTION

The bass boost/cut frequency curve has a peak at 20 Hz, the variable width becomes smaller toward the high range, and the variable width becomes zero at about 1000 Hz. The variable range becomes slightly larger in the high range than around 1000 Hz, but it becomes zero again near 5000 Hz. The variable range of the peak frequency is approximately ±15 dB. The treble boost/cut frequency curve draws a mountain-shaped curve with a peak at around 10,000 Hz and zero variable range around 100 Hz. The variable range of the peak frequency is approximately ±15 dB. The mid-boost/cut frequency curve creates a bell-shaped curve with a peak around 450 Hz, and the variable width becomes zero near 20 Hz and around 10,000 Hz. The variable range of the peak frequency is approximately ±15 dB.
OTHER FEATURES

Features

Accu-cast B300 Bridge

The Accu-cast B300 bridge affords precise intonation and delivers string-to-body vibration conductively.

PowerSpan Dual Coil pickups

Developed by Ibanez, the exposed pole pieces of the PowerSpan Dual Coil pickups produce a stronger signal and increase the response of the higher frequencies without sacrificing low end. The result is a tone rich in harmonic detail and dynamic expression.

Ibanez Custom Electronics 3-band EQ w/3-way Power Tap switch

The 3-band EQ works in conjunction with a coil tap switch for maximum control over a wide variety of professional bass tones. Tap Mode (single coil) creates a punchy, dynamic sound with superior articulation. Series Mode (humbucking) delivers a full, warm tone, and Power Tap Mode provides the best of both worlds-combining the clarity of the single coil with the fat bottom end of the humbucker.

Jatoba Fretboard

Jatoba has a reddish brown color which produces a rich mid range with a crisp high end.
